HD51 工具系列模具 |
|
P/N |
"A"
槽 |
"A"
长度 |
"B"
槽 |
"B" 长度 |
应用 |
INDENTS |
塞规 |
|
HD51-101 |
.325 HEX |
.125 |
.216 HEX |
.187 |
.325 / .216 Hexes |
|
|
|
HD51-105 |
.170 GAGE |
.250 |
|
|
#8 Insulated Terminals |
|
G682 |
|
HD51-106 |
.202 GAGE |
.312 |
|
|
#6 Insulated Terminals |
|
G683 |
|
HD51-107 |
.254 GAGE |
.375 |
|
|
#4 Insulated Terminals |
|
G684 |
|
HD51-110 |
.530 HEX |
.365 |
|
|
.530 Hex |
|
|
|
HD51-112 |
.440 HEX |
.358 |
.538 HEX |
.358 |
.440 / .538 Hexes |
|
|
|
HD51-113 |
.312 GAGE |
.470 |
|
|
#2 Insulated Terminals |
|
G801 |
|
HD51-114N |
.135 GAGE |
.312 |
|
|
#8 Uninsulated Terminals |
Single |
G744 |
|
HD51-115N |
.176 GAGE |
.312 |
|
, &nb, sp; |
#6 Uninsulated Terminals |
Single |
G745 |
|
HD51-116N |
.206 GAGE |
.312 |
|
|
#4 Uninsulated Terminals |
Single |
G746 |
|
HD51-117N |
.265 GAGE |
.312 |
|
|
#2 Uninsulated Terminals |
Single |
G747 |
|
HD51-118N |
.135 GAGE |
.312 |
|
|
#8 Uninsulated Terminals |
Double |
G744 |
|
HD51-119N |
.176 GAGE |
.312 |
|
|
#6 Uninsulated Terminals |
Double |
G745 |
|
HD51-120N |
.206 GAGE |
.312 |
|
|
#4 Uninsulated Terminals |
Double |
G746 |
|
HD51-121N |
.265 GAGE |
.312 |
|
|
#2 Uninsulated Terminals |
Double |
G747 |
|
HD51-122N |
.275 GAGE |
.470 |
|
|
#1/0 Uninsulated Terminals |
Single |
G749 |
|
HD51-123N |
.275 GAGE |
.470 |
|
|
#1/0 Uninsulated Terminals |
Double |
G749 |
|
HD51-124N |
.370 GAGE |
.470 |
|
|
#2/0 Uninsulated Terminals |
Double |
G750 |
|
HD51-125N |
.370 GAGE |
.470 |
|
|
#2/0 Uninsulated Terminals |
Single |
G750 |
|
HD51-127 |
.445 HEX |
.250 |
.395 HEX |
.200 |
.445 / .395 Hexes |
|
|
|
HD51-128 |
.410 GAGE |
.470 |
|
|
#1/0 Insulated Terminals |
|
G854 |
|
HD51-129 |
.404 GAGE |
.470 |
|
|
#2/0 Insulated Terminals |
|
G855 |
|
HD51-130-1 |
R .100,
H .300 |
|
|
|
#2 - #8 Uninsulated
Needs HD51-131-2
or HD51-132-2 |
Single
(MALE) |
|
|
HD51-131-2 |
R .275 |
|
R .145 |
|
#2 & #8 Uninsulated
Needs HD51-130-1 |
Single (FEMALE) |
G744
G747 |
|
HD51-132-2 |
R .219 |
|
R .188 |
|
#4 & #6 Uninsulated
Needs HD51-130-1 |
Single (FEMALE) |
G745
G746 |
|
HD51-133-2 |
.312 GAGE |
|
.170 GAGE |
|
#2 & #8 Insulated
Needs HD51-113-1 for #2
& HD51-105-1 for #8 |
(FEMALE) |
G801 (#2)
G682 (#8) |
|
HD51-134-2 |
.202 GAGE |
|
.254 GAGE |
|
#4 & #6 Insulated
Needs HD51-106-1 for #6
& HD51-107-1 for #4 |
(FEMALE) |
G683 (#6)
G684 (#4) |
|
HD51-138 |
.377 HEX |
.435 |
|
|
#2 Uninsulated .377 Hex
MS90485-2 Equiv. |
MS90485-2 Equiv. |
|
|
HD51-139 |
.587 HEX |
.400 |
|
|
.587 Hex |
|
|
|
HD51-140 |
.956 HEX |
|
.500 HEX |
|
.956 & .500 HEX |
|
|
|
HD51-144 |
.140 HEX |
.470 |
|
|
.130 Hex |
|
|
|
HD51-148 |
.216 HEX |
|
|
|
.216 Hex |
|
|
|
HD51-149 |
.660 HEX |
.400 |
|
|
.660 Hex |
|
|
|
HD51-150 |
.352 HEX |
.470 |
|
|
AB Twinax Pin & Socket Contacts |
|
|
|
HD51-152 |
.304 GAGE |
.470 |
|
|
Packard Hughes .437 Ferrules |
|
|
|
HD51-154 |
.339 GAGE |
.437 |
|
|
MS25036 #1
MS23002-1 Equiv. |
|
G726 |
|
HD51-157 |
|
|
|
|
#10 Flag Terminal |
|
|
|
HD51-159 |
.312 GAGE |
.470 |
|
|
#2 AWG Insulated |
Elongated Hex |
|
|
HD51-160 |
.500 HEX |
1.300 |
|
|
#2 Uninsulated
For Aluminum Wire |
|
|
|
HD51-162 |
.218 |
.470 |
|
|
.218 HEX |
|
|
